Scintillation materials based on solid solutions ZnSxSe1–x
Abstract
Composite materials based on ZnSxSe1–x solid solutions are promising materials for gamma and X-ray detectors. However, influence of compositions and particle size on scintillation properties is unclear, which prevents their application. This paper reports on the complex study of microcrystalline ZnSxSe1–x powdered scintillations, prepared by solid phase synthesis from ZnS and ZnSe initial compounds. ZnSxSe1–x solid solutions were obtained in the range of x from 0.07 to 0.86 and in the following sizes: 200—250 μm, 140—200 μm, 140—80 μm, and less than 80 μm.
X-ray diffractions of powder ZnSxSe1–x shows formation of a cubic lattice of sphalerite structure. ZnSxSe1–x powders demonstrate a presence of a luminescence band in the 590-615 nm regions, while an increase in sulfur concentration leads to a shift of the maximum intensity of X-ray induced luminescence to the short-wave region, which is associated with an increase of the band gap width. The best parameters of X-ray induced luminescence are obtained for the solid solution with 39 at.% of sulfur. The ZnS0,39Se0,61 solid solutions obtained under these conditions have an X-ray induced luminescence intensity that is 4 times higher than that of ZnSe(Al) single crystal and a relatively low level of afterglow.
In ZnSxSe1–x solid solutions, increasing of particle size leads to shifts of the X-ray induced luminescence to the longwave region. The highest intensity of the X-ray induced luminescence corresponds to the ZnS0,39Se0,61 composition with the particle size of less than 80 μm. Also, ZnS0,39Se0,61 solid solutions, with particle size less than 80 microns, are more homogeneous in composition, which is why the process of solid phase reaction in them passes more efficiently.
It is shown that the ZnSxSe1–x composite scintillators can be used as gamma and X-ray detectors. It has been established that the effectiveness of these materials depends on their composition. ZnS0,5Se0,5 and ZnS0,39Se0,61 composites demonstrate the best scintillation characteristics, with twice as high an efficiency as that of the «commercial» ZnSe(Al) composite.
References
Mizetskaya I. B., Oleinik G. S. Physical and chemical principles of the single crystals synthesis of semiconductor solid solutions of A2B6 compounds. Kiev, Naukova dumka, 1984.
Katrunov K., Lalaiants O., Baumer V., Galkin S., Galchinetskii L., Brilyova Y. Peculiarities of scintillation materials based on ZnS—ZnTe solid solutions. Functional materials, 2013, vol. 20, iss. 3, pp. 384-389. https://doi.org/10.15407/fm20.03.384
Starzhinskiy N.G. Scintillators based on AIIBVI compounds. Receipts, properties and features of obtaining. Kharkov, Institute for Single Crystals, 2007.
Fischer A.G. Preparation and properties of ZnStype crystals from the melt. Journal of Electrochemistry Society, 1959, vol. 106, iss. 9, pp. 838-839. https://doi. org/10.1149/1.2427507
Ryzhikov, V., Chernikov, V., Gal’chinetskii L. et al. The use of semiconductor scintillation crystals AIIBVI in radiation instruments. Journal of crystal growth, 1999, vol. 197, iss. 3, pp. 655-658. https://doi.org/10.1016/S0022-0248(98)00771-4
Trubaieva O.G., Lalayants A., Chaika M.A. Band gap change of bulk ZnSxSe1–x semiconductors by controlling the sulfur content. Ukrainian Journal of Physics. 2018, vol. 63, no. 1, pp. 33-37. https://doi.org/10.15407/ujpe63.01.0033
Galkin. S.N., Galchinetsky L.P., Katrunov K.A. The formation of CdS1–xTex solid solutions by sintering of CdS and CdTe powders. Inorganic materials, 1992, vol. 28, pp. 2058-2062.
Wreigth H., Barnard W., Heelbig J. Solid solutions in the systems ZnS—ZnSe and PbS—PbSe at 300°C and above. American Mineralogist. 1965, vol. 50, pp. 1802-1815.
Gurgula G.Ya., Bojchuk V.M., Vadyuk M.P., Freik N.D. Crystal chemistry of points defects of the solid solutions ZnSexS1–x. Physics and chemistry of the solid state, 2011, vol. 12, no. 2, pp. 395-401. (Ukr)
Woolley J.C., Ray B. Solid solution in AIIBVI tellurides. Journal of Physics and Chemistry of Solids, 1960, vol. 13, iss. 1-2, pp. 151-153. https://doi.org/10.1016/0022-3697(60)90135-9
Singh N.B., Su C.H., Arnold B., Choa F.S. Optical and morphological characteristics of zinc selenide-zinc sulfide solid solution crystals. Optical Materials, 2016, vol. 60, pp. 474-480. https://doi.org/10.1016/j.optmat.2016.08.031
Hajj Hussein R., Pagés O., Firszt F. et al. Near-forward Raman study of a phonon-polariton reinforcement regime in the Zn (Se, S) alloy. Journal of Applied Physics, 2014, vol. 116, iss. 8, pp. 083511. https://doi.org/10.1063/1.4893322
Hussein R. H., Pagиs O., Doyen-Schuler S. et al. Percolation-type multi-phonon pattern of Zn(Se, S): Backward/forward Raman scattering and ab initio calculations. Journal of Alloys and Compounds, 2015, vol. 644, pp. 704-720. https://doi.org/10.1016/j.jallcom.2015.04.078
Morozova N.K. Selenid tsinka. Poluchenie i opticheskie svoistva [Zinc selenide. Obtaining and optical
properties]. Мoskow, Nauka, 1992, 96 p.
Katsumi Mochizuki. Vapor growth and stoichiometry control of zink sulfo-selenide. Journal of Crystal Growth, 1982, vol. 58, pp. 87-94. https://doi.org/10.1016/0022-0248(82)90213-5
Koshkin V.M., Dulfan A.Y., Ganina N.V. et al. Tellurium, sulfur, and oxygen isovalent impurities in ZnSe semiconductor. Functional materials, 2002, vol. 9, no. 3, pp. 438-441.
Berchenko N.N., Krevs V.E., Sedin V.G. Poluprovodnikovye tverdye rastvory i ikh primenenie. Spravochnye tablitsy [Semiconductor solid solutions and their application.
Reference tables]. Мoskow, Voenizdat, 1982, 208 p. (Rus)
Kulakov M.P., Fadeev A.V. [Oxidation of mechanically polished zinc selenide when heated in air]. Izvestiyа. AN SSSR. Neorganicheskie materialy, 1988, vol. 19, no. 3, p. 347. (Rus)
Zuyev A.P., Kulakov M.P., Fadeyev A.V. The oxygen content in ZnS, ZnSe and CdS crystals grown from the melt. Izvestiyа. AN SSSR. Neorganicheskie materialy, 1981, vol. 17, no. 7, p. 1159. (Rus)
Sung H.J., Cho Y.S., Huh Y.D., Do Y.R. Preparation, characterization and photoluminescence properties of Ca1–xSrxS:Eu red-emitting phosphors for a white LED. Bulletin of the Korean Chemical Society, 2007, vol. 28, iss. 8, pp. 1280-1284. https://doi.org/10.5012/bkcs.2007.28.8.1280
Jia D., Zhu J., Wu B. Trapping centers in CaS:Bi3+ and CaS:Eu2+, Tm3+. Journal of the Electrochemical Society, 2000, vol. 147, iss. 1, pp. 386-389. https://doi.org/10.1149/1.1393205
Park H.L., Hwang Y.H. Physics of Alkaline-Earth Sulfide Phosphors. Chinese Journal of Physics, 1990, vol. 28, iss. 1, pp.105-113. https://doi.org/10.6122/CJP
Jia D., Wang X.J. Alkali earth sulfide phosphors doped with Eu2+ and Ce3+ for LEDs. Optical Materials, 2007, vol. 30, iss. 3, pp. 375-379. https://doi.org/10.1016/j.optmat.2006.11.061
Thiyagarajan P., Kottaisamy M., Sethupathi K., Rao M. S. R. Preparation and luminescent properties of SrS:Ce by addition of sulphur as a co-activator in SrSO4:Ce(SO4)2∙4H2O by carbothermal reduction. Proceedings of the Materials Research Society, 2005, vol. 829, pp. 331-337. https://doi.org/10.1557/PROC-829-B2.33
Sun J.Y., Sun R.D., Du H.Y. Synthesis and characterization of nanosized phpsphor SrS: Eu2+, Sm3+ by a hydrothermal process. Advanced Materials Research, 2011, vol. 295, pp. 531-534. https://doi.org/10.4028/www.scientific.net/AMR.295-297.531
Kojima Y., Toyama T. Effect of strontium and lithium ions on afterglow time of red-emitting CaS: Eu2+, Pr3+ phosphor upon visible-light irradiation. Journal of Alloys and Compounds, 2009, vol. 475, iss. 1-2, pp. 524-528. https://doi.org/10.1016/j.jallcom.2008.07.079
Pitale S.S., Sharma S.K., Dubey R.N. et. al. TL and PL studies on defect-assisted green luminescence from doped strontium sulfide phosphor. Journal of Luminescence, 2008, vol. 128, iss. 10, pp. 1587-1594. https://doi.org/10.1016/j. jlumin.2008.03.002
Volkov A.I., Zarskij I.M. Bol’shoi khimicheskii spravochnik [Great chemical directory]. Мinsk, Sovremenyaja Shkola, 2005, 605 p. (Rus)
Karapet’yants M.H. Khimicheskayа termodinamika [Chemical thermodynamics]. Moskow, Chemistry, 1975. (Rus)
Georgobiani A. N. Kotlyarevskyi. [The problem of controlling the composition of point defects in compounds AIIBVI. Physics of compounds AIIBVI]. Sbornik nauchnykh trudov, Moskow, Nauka, 1986, pp. 72-108. (Rus)
Watkins, G. D. Intrinsic defects in II–VI semiconductors. Journal of crystal growth, 1996, vol. 159, iss. 1-4, pp. 338-344. https://doi.org/10.1016/0022-0248(95)00680-X
Hopfield J.J., Thomas D.G., Lynch R.T. Isoelectronic donors and acceptors. Physical Review Letters, 1966, vol. 17, iss. 6, pp. 312. https://doi.org/10.1103/PhysRevLett.17.312
