Investigation of the influence of oxygen on the rate and anisotropy of deep etching of silicon in the plasma-chemical reactor with the controlled magnetic field

V. V. Hladkovskyi; O. A. Fedorovich

doi:10.15222/TKEA2017.4-5.40

V. V. Hladkovskyi Institute for Nuclear Research of NASU, Kyiv, Ukraine
O. A. Fedorovich Institute for Nuclear Research of NASU, Kyiv, Ukraine

DOI: https://doi.org/10.15222/TKEA2017.4-5.40

Keywords: deep etching of silicon, ion energy, plasma chemistry, anisotropy

Abstract

The article presents the research results on the influence of the amount of oxygen in a mixture with sulfur hexafluoride on the rate and anisotropy of the silicon etching in the plasma-chemical reactor with the controlled magnetic field. The etching was performed under the pressure of (0,3—2,0)·10^–3 Torr in the working chamber and the energy of chemically active ions of 50—80 eV. It was possible to etch the silicon to the depth of 100 µm with anisotropy 10, using a thick (0.4—1 µm) nickel mask. The obtained results make it evident, that maximums do not coincide for speed of etch and anisotropy. The maximum of etch rate is observed at oxygen maintained at 5%. While the maximum of anisotropy is observed at 10% oxygen. The authors discovered the influence of the magnetic field on the rate and anisotropy of etching. Etch rate of the silicon at the increase of the magnetic-field tension increases virtually twofold at other discharge parameters remaining unchanged. The anisotropy first increases, and then decreases sharply. Thus, the increase of the tension of magnetic field results in worsening of anisotropy. Thus, the process of deep plasma-chemical etching of silicon has been developed and optimized.

References

Mogab C. J., Adams A. C., Flamm D. L. Plasma etching of Si and SiO2 — The effect of oxygen additions to CF4 plasmas. Journal of Applied Physics, 49, 3796 (1978). http://dx.doi.org/10.1063/1.325382

Gurvich L.V. et al. Energii razryva himicheskih svyazey. Potentsialy ionizatsii i srodstvo k elektronu. Moskow, Nauka, 1974, 351 p. (Rus)

Fedorovich O.A., Kruglenko M.P., Polozov B.P. [Peculiarity of plasmachemical etching of silicon plate edges of photoelectric converters]. Tekhnologiya i Konstruirovanie v Elektronnoi Apparature, 2009, no 6, pp. 46-49. (Rus)

Riccardo d’Agostino, Daniel L. Flamm. Plasma etching of Si and SiO2 in SF6–O2 mixtures. Journal of Applied Physics, 1981, vol. 52, p.162. http://dx.doi. org/10.1063/1.328468

Kostin E.G., Ustalov V.V., Fedorovich O.A. Zbirnyk naukovykh Prats of Institute for Nuclear Research, 2004, no. 2 (13), pp. 86-95. (Rus)

J. Yoo, K. Kim, M. Thamilselvan, N. Lakshminarayn, Y. K. Kim K. J. Yoo, J. Yi. RIE texturing optimization for thin c-Si solar cells in SF6/O2 plasma. J. Phys. D: Appl. Phys. 41, 125205 (2008). [http://dx.doi.org/10.1088/0022-3727/41/12/125205]

Khaled A. Alshaltami, Muhammad Morshed, Cezar Gaman, Jim Conway, Stephen Danielsl. Experimental investigation of SF6–O2 plasma for advancement of the anisotropic Si etch process. Journal of Vacuum Science & Technology A: Vacuum, Surfaces, and Films, 2017, vol. 35, iss. 3. http://dx.doi.org/10.1116/1.4981785

Fedorovich O.A., Hladkovskiy V.V., Polozov B.P., Kruglenko M.P. The bias voltage and its influence on the etching rate of silicon. Probl. At. Sci. Technol., 2015, no. 6 (100), pp. 146-150.

Ustalov V.V., Konoval V.M., Fedorovich O.A. Proc. of the 6th Int. konfer. “Microwave & Telecommunication Technologies (Krymiko 96)”, Sevastopol’, Crimea, Ukraine, 1996, pp. 285-288. (Rus)

Hladkovskiy V.V., Fedorovich O.A. Spectroscopic studies of RF discharge plasma at plasma-chemical etching of gallium nitride epitaxial structures. Ukr. J. Phys., 2017, vol. 62, no. 3, pp. 208-213. http://dx.doi.org/10.15407/ujpe62.03.0208

Boltovec N. S., Borisenko A. G., Ivanov V. N., Fedorovich O. A., Krivuca V. A., Polozov B. P. [Forming of 4НSiC p–i–n-diodes mesastructures by the ion-plasmous etching method]. Tekhnologiya i Konstruirovanie v Elektronnoi Apparature, 2009, no. 5, pp. 45-48. (Rus)

Chase M.W. NIST-JANAF Thermochemical Tables. Journal of Physical and Chemical Reference Data, 1996, vol. 25, iss. 2. http://dx.doi.org/10.1063/1.555992

Gal’perin V.A., Danilkin E.V., Molchanov A.I. Processy plazmennogo travleniya v mikro- i nanotehnologiyakh. Moskow, Binom, 2012, 283 p. (Rus)

Danilin B.S., Kireev V.Ju. Primenenie nizkotemperaturnoy plazmy dlya travleniya i ochistki materialov. Moskow, Energoatomizdat, 1987, 264 p. (Rus)

Hladkovskiy V.V., Fedorovich О.А., Polozov B.P., Kruglenko M.P. Аbout peculiarities of self-bias voltage formation in plasmachemical reactors with controlled magnetic fields. Problems of Atomic Science and Technology, no. 1, Series: Plasma Physics, 2015, pp. 156-160.
