The retunable SHF-range signal delay line based on ferroelectrics and diamond films

  • M. S. Afanasyev V. A. Kotelnikov IRE RAS, Moscow, Russia
  • A. Yu. Mityagin V. A. Kotelnikov IRE RAS, Moscow, Russia
  • G. V. Chucheva V. A. Kotelnikov IRE RAS, Moscow, Russia
Keywords: delay line, ferroelectric, diamond film

Abstract

The article describes the principles of creation of a broadband miniature SHF-range signal delay line based on ferroelectrics and diamond films. The parameters of obtained ferroelectrics and diamond films have been given. The possible design of the delay line, executed as a micro strip transfer line of SHF-range signal with the concentrated planar variable capacity condensers is shown.

Published
2010-06-28
How to Cite
Afanasyev, M. S., Mityagin, A. Y., & Chucheva, G. V. (2010). The retunable SHF-range signal delay line based on ferroelectrics and diamond films. Technology and Design in Electronic Equipment, (3), 3-6. Retrieved from https://tkea.com.ua/index.php/journal/article/view/TKEA2010.3.03
Issue
No. 3 (2010): Tekhnologiya i konstruirovanie v elektronnoi apparature
Section
Articles

Copyright (c) 2010 Afanasyev M. S., Mityagin A. Yu., Chucheva G. V.
